Water 4 Life
Solve Macro Water Challenges
- Global Warming
- Hydropower
- Floods
- Droughts
- Irrigation
- Pollution Control
Failure-Free Automation
Leading the way to secure and control valuable water resources.
World-class, 100% automatic, self-actuating water control equipment.
No external power required. No operator error.
200+ installations 4 continents Zero external power
50+
Years of Excellence
100+
Years Combined Experience
200+
Global Installations
4
Continents Served
Two ways we work
Choose your path forward
Whether you are a consultant solving a catchment-wide challenge or an engineer specifying a single valve, Amanziflow meets you where the problem begins.
Engineering CatalogueView Technical Specs
Specify Technical Equipment
Valves
Diaphragm · Reservoir inlet · Irrigation · Dam outlet
Gates
Scour · Crest · Tidal · Canal
Flagship equipment
The award-winning equipment Amanziflow is known for
The automatic, self-actuating systems at the heart of most of our installations — storing more water, keeping it clean, and handing it on precisely where it is needed.
AG-TOPS · Spillway gate
TOPS Spillway Gate
Raises the full supply level of existing or new dams by 0.5 m to 10 m — increasing storage without raising the dam wall.
It installs on straight or curved ogee spillways without modifying the spillway crest, using a unique outward and upward motion that rides on the water it stores — no external power, sensors or controllers required.
- FSL raise
- 0.5 m – 10 m
- Spillway
- Straight or curved ogee
- Crest
- No modification required
- Motion
- Outward and upward
- Override
- Manual / telemetry option
- Actuation
- Self-actuating
Used atDam spillways · Full supply level raising · Flood routing
Additional storage
up to 10 m
raised full supply level per dam
AV-DM · Flow control valve
Diaphragm Valve
Control valve for precise flow, and closing off for irrigation dams when storage is full.
A line-pressure diaphragm operator regulates flow and head without motors or power. A manual locking device is available where the valve must be held shut for maintenance or isolation.
Precise flow and head control
The diaphragm operator holds the set flow across the working head range.
Shuts off when storage is full
Closes the supply to irrigation dams rather than overfilling them.
Manual locking when required
A locking option holds the valve in position for maintenance or isolation.
- Diameters
- 0.15 m – 1.6 m
- Head loss
- 0.5 m – 60 m
- Outlet
- Top / bottom
- Option
- Manual locking
- Actuation
- Line pressure
- Power
- None required
Used atCanal offtakes · Pressure control · Irrigation schemes
AG-SC · Sediment removal
Scour Gate
Protects dam storage by flushing sediment before it settles — and restores full supply level as floodwaters recede.
Installed at the base of dams and river weirs, it opens automatically during flood events to pass sediment-laden water, then closes automatically to retain the full supply level. No electro-mechanical operation and no external power.
Passes sediment in flood
Opens automatically during flood events to flush sediment-laden water downstream.
Retains supplied storage
Closes as floodwaters recede — holding back water instead of releasing it.
Self-actuating, no power
Runs on non-electro-mechanical actuation, with manual operation for scheduled flushing.
- Operation
- Automatic
- Flood response
- Opens automatically
- Drawdown
- Closes at FSL
- Override
- Manual flushing
- Actuation
- Non-electro-mechanical
- Power
- None required
Zero
External power, sensors or controllers required
The Amanziflow DifferenceLearn about our legacy
Self-actuating by design. Dependable by nature.
Our valves and gates harness the very water they control. There are no motors, no PLCs and no batteries to fail — just proven hydraulic principles engineered to operate through storms, outages and decades of service.
No external power
Fully self-actuating: the equipment runs on the pressure and level of the water itself.
No operator error
Removes the human variable from flood response and level control, day or night.
Built to outlast
Marine-grade fabrication and pressure-tested assemblies for Infrastructure that must endure.
How we deliver
End-to-End Project Capabilities
From the first hydraulic calculation to the final handover, one accountable team carries your project through every stage.
01
Design
Assisting consultants with hydraulic modelling, sizing and specification support.
02
Fabrication & Construction
Precision fabrication and quality-controlled assembly of valves and gates.
03
Installation
On-site installation and alignment by experienced field engineering crews.
04
Commissioning & Handover
Testing, calibration, documentation and operator training for confident operation.
Talk to our engineers
Bring us the challenge. We will size the solution.
Consultants, utilities and contractors rely on Amanziflow for equipment that keeps working when power, staff and schedules do not. Tell us about your site and we will come back with a practical, engineered recommendation.
Emailinfo@amanziflow.com
Head officeSouth Africa — serving projects worldwide
